| Unit box width: | 0.086 |
| Units per shipping box: | 1 |
| Unit calculated volume: | 0.008228 |
| Rack mounting: | Jā |
| Wall mountable: | Jā |
| Unit box length: | 0.368 |
| Summary: | Ubiquiti UniFi Enterprise 8 PoE. Switch type: Managed, Switch layer: L3. Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500), Basic switching RJ-45 Ethernet ports quantity: 8. Switching capacity: 80 Gbit/s. Networking standards: IEEE 802.3af, IEEE 802.3at. Power over Ethernet (PoE). Wall mountable, Rack mounting |
| Switch layer: | L3 |
| Switching capacity: | 80 |
| Forwarding rate: | 59.52 |
| Unit box height: | 0.26 |
| Ac input voltage: | 100 - 240 |
| Model name: | Enterprise 8 PoE |
| Switch type: | Managed |
| Unit calculated weight: | 2.76 |
| 10g support: | No |
| Networking standards: | IEEE 802.3af/IEEE 802.3at |
| Throughput: | 40 |
| Housing material: | Polycarbonate (PC) |
| Led indicators: | Activity/Link |
| Product colour: | Stainless steel |
| Sfp+ module slots quantity: | 2 |
| Vendor homepage: | https://eu.store.ui.com/collections/unifi-network-routing-switching/products/switch-enterprise-8-poe |
| Description: | Layer 3, PoE switch with (8) 2.5GbE, 802.3at PoE+ RJ45 ports and (2) 10G SFP+ ports. The Switch Enterprise 8 PoE (USW Enterprise 8 PoE) is a fully managed, Layer 3* switch with (8) 2.5GbE, 802.3at PoE+ RJ45 ports and (2) 10G SFP+ ports.The USW Enterprise 8 PoE also features a 1.3" LCM color touchscreen that concisely displays key system and connection insights. This switch can be monitored or configured from anywhere with the powerful, intuitive UniFi Network web application and mobile app. - (1) 1.3" LCM color touchscreen with AR switch management
- (8) 2.5GbE, 802.3at PoE+ RJ45 ports
- (2) 10G SFP+ ports
- 120W total PoE supply
- Wall-mountable (kit included)
|
| Input current: | 2 |
| Power supply included: | Jā |
| Ac input frequency: | 50 - 60 |
| Power over ethernet (poe): | Jā |
| Power over ethernet (poe) power per port: | 32 |
| Power over ethernet plus (poe+) ports quantity: | 8 |
| Total power over ethernet (poe) budget: | 120 |
| Operating relative humidity (h-h): | 10 - 95 |
| Operating temperature (t-t): | -5 - 45 |
| Depth: | 200 |
| Height: | 44 |
| Weight: | 2400 |
| Width: | 248 |
| Manual: | Jā |
| Compliance certificates: | CE |
| Harmonized system (hs) code: | 85176990 |
| Basic switching rj-45 ethernet ports type: | 2.5G Ethernet (100/1000/2500) |
| Basic switching rj-45 ethernet ports quantity: | 8 |
| Web-based management: | Jā |
